Capacity: upto 2500 KVA of voltage class up to 33kv
Makpower takes pride in presenting Energy-Efficient Distribution Transformers which are a pinnacle in transformer technology. We are one of the few leaders in the Industry having BIS Certification for manufacturing Distribution Transformers up to 2500 KVA 33KV Energy Efficiency Level III as per the latest amendment i.e., No. 4 to IS:1180.
Key Features:
• The efficiency of distribution transformers ranges from 25 KVA to 6000 KVA capacity.
• The distributor transformer functions in versatile voltage options of 3.3KV/6KV/6.6KV/11KV/22KV/33KV
• There are two types of distribution transformers available in both indoor and outdoor configurations for higher adaptability.
• With a default option of Dyn-11, these transformers are configured to meet specific requirements.
• Uses EHV-grade oil, meeting the stringent IS: 335 specifications.
• Complies with IS: 1180 & IS: 2026 for reliability and quality assurance.
The following distributor transformer specifications make it versatile and unique in the market.
• Capacity - 25KVA to 6000 KVA
• Rated Voltage (Primary) - 3.3KV/6KV/6.6KV/11KV/22KV/33KV
• Type - Indoor or Outdoor
• Vector Group - Dyn-11 (or any other group as per requirement)
• Frequency - 50Hz.
• Tappings - ±5%, ±7.5%, ±10% ( or any other Tapping as per requirement)
• Temperature Rise - As per IS 2026 / IS 1180
• Cooking - Naturally oil cooled (ONAN)
• Winding Material - Copper
• Grade of Oil - EHV Grade, as per IS: 335
• Standard - IS: 1180 & IS: 2026
Sl |
Rating |
Impedance |
Maximum Total Loss (W) |
|||||||||
|
|
|
Energy Efficiency |
Energy Efficiency |
Energy Efficiency |
Energy Efficiency |
Energy Efficiency |
|||||
|
|
|
50 |
100 |
50 |
100 |
50 |
100 |
50 |
100 |
50 |
100 |
1. |
16 |
4.50 |
135 |
440 |
120 |
400 |
108 |
364 |
97 |
331 |
87 |
301 |
2. |
25 |
4.50 |
190 |
635 |
175 |
595 |
158 |
541 |
142 |
493 |
128 |
448 |
3. |
63 |
4.50 |
340 |
1140 |
300 |
1050 |
270 |
956 |
243 |
870 |
219 |
791 |
4. |
100 |
4.50 |
475 |
1650 |
435 |
1500 |
392 |
1365 |
352 |
1242 |
317 |
1130 |
5. |
160 |
4.50 |
670 |
1950 |
570 |
1700 |
513 |
1547 |
462 |
1408 |
416 |
1281 |
6. |
200 |
4.50 |
780 |
2300 |
670 |
2100 |
603 |
1911 |
543 |
1739 |
488 |
1582 |
7. |
250 |
4.50 |
980 |
2930 |
920 |
2700 |
864 |
2488 |
811 |
2293 |
761 |
2113 |
8. |
315 |
4.50 |
1025 |
3100 |
955 |
2750 |
890 |
2440 |
829 |
2164 |
772 |
1920 |
9. |
400 |
4.50 |
1225 |
3450 |
1150 |
3330 |
1080 |
3214 |
L013 |
3102 |
951 |
2994 |
10. |
500 |
4.50 |
1510 |
4300 |
1430 |
4100 |
1354 |
3909 |
1282 |
3727 |
1215 |
3554 |
11. |
630 |
4.50 |
1860 |
5300 |
1745 |
4850 |
1637 |
4438 |
1536 |
4061 |
1441 |
3717 |
12. |
800 |
5.00 |
2287 |
6403 |
2147 |
5838 |
2015 |
5323 |
1892 |
4853 |
1776 |
4425 |
13. |
1000 |
5.00 |
2790 |
7700 |
2620 |
7000 |
2460 |
6364 |
2310 |
5785 |
2170 |
5259 |
14. |
1250 |
5.00 |
3300 |
9200 |
3220 |
8400 |
3142 |
7670 |
3066 |
7003 |
2991 |
6394 |
15. |
1600 |
6.25 |
4200 |
11800 |
3970 |
11300 |
3753 |
10821 |
3547 |
10363 |
3353 |
9924 |
16. |
2000 |
6.25 |
5050 |
15000 |
4790 |
14100 |
4543 |
13254 |
4309 |
12459 |
4088 |
11711 |
17. |
2500 |
6.25 |
6150 |
18500 |
5900 |
17500 |
5660 |
16554 |
5430 |
15659 |
5209 |
14813 |
• These transformers can achieve level III energy efficiency minimizing energy wastage.
• There is a wide range of distribution transformer voltage and capacities for diverse applications.
• Following the BIS and IS standards, these transformers ensure quality and dependability.
• Copper welding and high-grade oil make them effective for long-term use.
The following is a list of applications of distribution transformers -
• Industrial Sector: Suitable for a range of industries requiring reliable power distribution.
• Utilities: Suitable for outdoor use in utility applications.
• Infrastructure Projects: Versatile options for different voltage requirements in large-scale projects.
• Energy Conservation: Level III Energy Efficiency supports sustainable and eco-friendly practices.
A Distribution Transformer is a type of transformer designed for the final delivery of electric power to end-users, typically at lower voltages.
Yes. You can choose from a range of rated voltages, including 3.3KV, 6KV, 6.6KV, 11KV, 22KV, and 33KV.
Yes, our transformers are available in both indoor and outdoor configurations for maximum adaptability.
We use natural oil cooling for our transformers. It is effective in heat dissipation and optimal performance.
Our Energy-Efficient Distribution Transformers comply with IS: 1180 and IS: 2026 to ensure reliability and quality.
Power transformer vs distribution transformer:
• A distribution transformer is a particular kind of transformer used to supply electricity to consumers in the end, usually at lower voltages. On the other hand, a Power Transformer is employed for the long-distance transmission of high-voltage power.
• Distribution Transformers are typically smaller, lighter, and designed for lower voltage levels, while Power Transformers are larger and built for high-voltage transmission.
Distribution Transformers offer localized voltage transformation, improving efficiency and minimizing power losses in the distribution network. They are compact, cost-effective, and essential for safe power delivery to homes and businesses.
Despite these advantages, distribution Transformers are optimized for local power distribution but may not be suitable for long-distance power transmission due to their lower voltage ratings. Power Transformers, on the other hand, are designed for high-voltage, long-distance transmission.
The testing procedure for Distribution Transformers involves various parameters, including insulation resistance, turns ratio, oil quality, and temperature rise. These tests ensure the transformer's reliability and compliance with industry standards.
